PRODUCTS
Components
ATmega2561 modules
-
CPU: ATmega2561
-
CLOCK: 16MHz
-
ISP(10pin) Connector
-
JTAG(10pin) Connector
-
RESET PUSH SWITCH
-
External power regulator +5Vcc (Power connector)
-
SIZE: 88 x 55 (mm)
8key_switch modules
-
8 input switches
-
Output control of FND, LED, etc. is possible
-
10pin connector for connection with other modules
-
SIZE: 53 x 30 (mm).
LED modules
-
8 LEDs arranged in a row
-
Color: RED
-
10pin connector for
connection to the main module
-
SIZE: 39 x 30 (mm)
Text-LCD modules
-
Uses 1 control port and 1 data port
-
The brightness of the LCD can be adjusted with the variable resistor on the side
-
8 x 2 Text LCD
Graphic-LCD modules
-
Uses 1 control port and 1 data port
-
The brightness of the LCD can be adjusted with the variable resistor on the side
-
128 x 64 Graphic LCD
-
Print various characters, symbols
and pictures
LED modules
-
8 LEDs arranged in a row
-
Color: RED
-
10pin connector for
connection to the main module
-
SIZE: 39 x 30 (mm)
4x4Key Pad modules
-
Arrange 12 switches in 3 x 4
-
2 pins horizontal and 5 pins vertically Uses a total of 1 port
UART Communication modules
-
5 pins horizontal and 2 pins vertical
Uses 2 data ports -
UART data communication
Bluetooth modules
-
Uses 1 data port
-
bluetooth communication control
SMPS modules
-
SMPS circuit arrangement
-
With 2 input pins
and 4 output pins
A total of 1 port is used.
-
Outputs 12V input voltage
as 3.3V, 5V
Products Examples of use
ATmega2561 modules
+
LED modules
ATmega2561 modules
+
LED modules
+
8key_switch modules
ATmega2561 modules
+
C-LCD modules
ATmega2561 modules
+
LED modules
+
8key_switch modules
+
C-LCD modules
